32 TOW BEHIND DR
®
FIELD and BRUSH MOWER
Ref# Part# Description
75 265771 Bracket, Canister
76 127971 Cable Tie, 17" Long
77 265791 Screw, 6-32 X 1/2", Phil Pan, ZP
78 278221 Nut, 6-32, Nylon Lock
79 101811 Washer, Lock, 1/4", Split, ZP
80 265801 Hose, Vapor, 3/16", ID
81 265811 Clamp, Vapor Hose
82 277101 Cap, Fuel W/ Tether
(included in item 67)
83 296751 Grommet, Vapor Valve
(included in item 67)
84 296741 Valve, Fuel Tank Vapor
(included in item 67)
Items Not Illustrated
140021 Tubing, Oil Drain
265361 Bolt, Serrated Flange, M6-1 x 16 (15HP
Kohler for ground wire)
142201 Fuse, 20 Amp, Type AGC
229001 Fuse, 7 Amp, Type AGC
112141 Cable Tie, 7-1/2" L
Safety and Information Labels
230931 Label, DR Tow-Behind Field & Brush
Mower
240531 Label, DR, 4" Round
136491 Label, Danger
136831 Label, Caution Hot Surface
137581 Label, Check Oil
230901 Label, Serial Number
298341 Label, EPA Cert, 2012
