CONTACT US AT www.DRpower.com 31
Chapter 6: Parts Lists and Schematic Diagrams
Parts List - Deck and Drive Assembly (For Premier specific parts see page 34)
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
01 229501 Deck w/Labels
02 221361 Support, Deck
03 222131 Bolt, 5/16-18 x 3-5/8", HCS, GR5, ZP
04 112411 Washer, Flat, 5/16", USS, ZP
05 110761 Nut, Nylon Lock, 5/16-18, ZP
06 222451 Valve, 3/8" NPT, Oil Drain
07 221381 Mount, Tow Bar, Deck
08 222461 Bolt, 3/8-16 x 3/4", HCS, GR8, ZP, YZP
09 222471 Bolt, 3/8-16 x 2-1/4", HCS, GR8, ZP, YZP
10 180811 Washer, Lock, 3/8", Split
11 221291 Spindle, Housing
12 228881 Bolt, 3/8-16 x 1", HCS, GR8, ZP, YZP
13 110751 Nut, Nylon Lock, 3/8-16, ZP
14 221301 Shaft, Spindle, w/Key & Bearing
15 221311 Bearing, Ball, 30mm Bore
16 221321 Pulley, 12.00" EOD, 1.00" Bore
17 157451 Washer, Flat, 5/8", USS, ZP
18 221261 Nut, Nylon Lock, 5/8-18, Low Profile, ZP
19 212401 Spindle Hub, 30mm Bore
20 221221 Blade Carrier
21 101771 Washer, .64" ID x 2-1/4" OD x 3/8", ZP
22 212581 Washer, Lock, 5/8", Split, Heavy Duty, YZP
23 212411 Bolt, 5/8-18 x 1-3/4", HCS, GR8, ZP, YZP
24 221211 Blade, Swinging, 16-1/2" x 2-1/2"
25 312641 Nut, 5/8-18, Nylon Loc, GR8, ZP
26 234021 Bolt, 5/8"-18 x 1-1/2", GR8, ZP
27 285191 Engine, 15HP, Kohler, E/S
289891 Engine, 20HP, Kohler, E/S
28 289921 Muffler and Manifold, 20HP Kohler
285211 Muffler and Manifold, 15HP Kohler
29 221371 Mount, Engine
30 228851 Bolt, 5/16-18 x 1-1/2", HCS, GR8, ZP
31 229271 Bolt, 5/16-18 x 1-3/4", HCS, GR8, ZP
32 221421 Spacer, Clutch
33 191241 Clutch, Electric, 75 ft-lbs (15HP Kohler)
285221 Clutch, Electric, 95 ft-lbs (20HP Kohler)
34 142321 Key, Square, 1/4" x 1", Steel
35 191301 Washer, Flat, .469" ID x 1-5/8" OD x 1/4"
36 222521 Washer, Lock, 7/16", Heavy Duty
Ref# Part# Description
37 222141 Bolt, 7/16-20 x 2-1/4", Locking, HCS, GR8
38 221411 Anti-Rotation Bracket
39 123211 Bolt, 5/16-18 x 3/4", HCS, GR5, ZP
40 221331 Belt, BP51, 5/8" x 53.8"
41 222201 Idler Arm
42 222211 Bushing, .390" ID x .625" OD x .78"
43 119851 Bolt, 3/8-16 x 1-1/2", HCS, GR5, ZP
44 112391 Washer, Flat, 3/8", USS, ZP
45 151271 Pulley, Flat Idler, 4", 3/8" Bore
46 150691 Bolt, 3/8-16 x 2-1/2", HCS, GR5
47 150941 Spring, Ext., 3/4" OD x 5" L
48 179261 Bolt, 3/8-16 x 3-1/2", HCS, GR5, ZP, Full
Thread
49 289491 Wire Harness, Solenoid
50 152501 Bolt, 1/4-20 x 3/4", HCS, w/Flange
51 101811 Washer, Lock, 1/4", Split, ZP
52 112381 Washer, Flat, 1/4", USS, ZP
53 230811 Strain Relief, 1/2" Cord
54 104831 Battery, 12V, 17Ah
55 124511 Clamp, Battery, 7-1/8" X 5-1/2"
56 111481 Bolt, 1/4-20 x 1-3/4", HCS, GR5, ZP
57 110731 Nut, Nylon Lock, 1/4-20, ZP
58 150141 Wire, Ground, 16"
59 112431 Washer, Lock, 5/16", Split, ZP
60 247261 Cover, Belt w/Label
61 229521 Cover, Clutch Access w/Label
62 112481 Washer, Lock, 1/4", Ext. Tooth
63 240541 Strain Relief, .5" Cord
64 164131 Nut, Nylon Lock, 3/8-16, Low Profile
65 289901 Bolt, Tri Lobe, 3/8-16 x 1"
66 283371 Mount, Fuel Tank
67 283361 Fuel Tank, 2.5 Gal, Certified
68 222371 Strap, 2.5 Gal Tank
69 110701 Nut, Hex, 1/4-20, ZP
70 222441 Grommet, 1/2" ID x .12" Mount, Rubber
71 222391 Valve, Fuel Shutoff
72 100661 Clamp, Fuel Line
73 211661 Hose, Fuel, Certified
74 265751 Carbon Canister, 300cc, 3/16" Ports
