Chapter 3 BIOS Setup
Chapter 3
Enable or Disable Serial
Port (COM)
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Serial Port 3 Confi guration
Serial Port
Device Settings
Change Settings
Advanced
[Enabled]
IO=3E8h; IRQ=10;
[Auto]
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enable or Disable Serial
Port (COM)
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Serial Port 4 Confi guration
Serial Port
Device Settings
Change Settings
Advanced
[Enabled]
IO=2E8h; IRQ=11;
[Auto]
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enable or Disable Serial
Port (COM)
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Serial Port 5 Confi guration
Serial Port
Device Settings
Change Settings
Advanced
[Enabled]
IO=2F0h; IRQ=10;
[Auto]
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enable or Disable Serial
Port (COM)
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Serial Port 6 Confi guration
Serial Port
Device Settings
Change Settings
Advanced
[Enabled]
IO=2E0h; IRQ=11;
[Auto]
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Serial Port
Enable or disable the serial COM port.
Change Settings
Select the IO/IRQ settings for the super I/O device.
