Pg-03 terminal descriptions – Delta Electronics Pulse Generator Card PG-03 User Manual
Page 3
3
PG-03 Terminal Descriptions
Terminals
Terminal Symbols
Descriptions
+12V
Power Supply of the Encoder: +12V
Output Voltage: +12V
±5% 200mA
0V
Common point for the power supply and the signal
Encoder signal input (select the output type of the Encoder from FSW2)
Both single-phase input and two-phase input available
Maximum: 500KP/Sec
A/O, B/O
The Encoder signal output
Maximum: DC24V 50mA
Common point for signal grounding
Wiring Notes
1. Please use a shield cable to prevent interference. Do not run control wire parallel to any high
voltage AC power line (220 V and up).
2. Connect shielded wire to E only.
3. Recommended wire size 0.21 to 0.81mm
2
(AWG24 to AWG18).
4. Wire
length:
The Output Types of the
Encoder
Maximum Wire
Length
Wire Gauge
Output Voltage
50m
Open Collector
50m
Line Driver
300m
Complementary 70m
1.25mm
2
(AWG16) or above
