Ad panels are designed to attach directly to either side of the scoreboard using mounting
channels (Figure 9).
1. Use the 8 screws (16 total) to secure both the top and bottom mounting channels off
of the appropriate side(s) of the scoreboard.
2. Attach both the front and rear panels to the mounting channels using the 16 screws.
3. After attaching the ad panels to the scoreboard, secure the scoreboard and/or ad
panels to the beams using the C-channel method shown in Figure 6 & Figure 7 of
Section 3.3.
Figure 9: Side Ad Panel Mounting
Note:
Be sure to attach any side ad panels to the scoreboard before mounting the display to
the support beams. Depending on the number of ad panels, the display may require a
different number and arrangement of beams. Refer to the installation specifications listed in
Section 3.1
and Appendix A.
