Evaluation procedure (dep-003), 0 purpose, 0 relevant documentation

background image

1

Delta Electronics, Inc.

1.0 Purpose

This document guides the user in performing
electronic measurements on an IPM POL (point
of load) DC/DC converter using the Delta
Evaluation Board.


2.0 Relevant Documentation

The documentation and background information
listed below is relevant to this evaluation
procedure:

Applicative date sheets for IPM Series unit

under evaluation.

Power Module Evaluation Board Schematic.

Power Module Evaluation Board Layout.

․ General Test and Safety Procedures.



IPM Series



Evaluation Procedure
EP_IPMC_04292005

Evaluation Procedure
(DEP-003)

The IPM- C Series POL converters


The IPM Series, single output,

non-isolated

point of load DC/DC converters, are the latest
offering from a world leader in power systems
technology and manufacturing ― Delta
Electronics, Inc. They operate from a
3V~5.5V (IPM04C) or an 8V~14V (IPM12C)
source and provide a programmable output
voltage of 0.8V to 3.3V(IPM04C) or 0.8V to
5V(IPM12C). With creative design technology
and optimization of component placement,
these converters possess outstanding
electrical and thermal performance, as well
as offering extremely high reliability under
highly stressful operating conditions. All
models are protected against abnormal
input/output voltage and current conditions.

This document guides the user through the
evaluation procedure to qualify a POL module.
The data shown in this Evaluation Procedure
is for the SIP and SMT Package Type POL
evaluation board. Please refer to the
appropriate technical data sheet for detailed
performance and technical information for the
specific POL units.
