www.desatech.com 111244-01C 37
PARTS LIST
THERMOSTAT MODELS
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 42 of this manual.
KEY FDCFTP FDCFTN
NO. VDCFTP VDCFTN CDCFTP CDCFTN DESCRIPTION QTY
1 111069-01 111069-01 111069-01 111069-01 Dual Burner 1
2 099056-29 099056-34 099056-29 099056-34 Injector 1
3 104424-04 104424-04 104424-04 104424-04 Outlet Tube 1
4 111124-01 111124-01 111124-01 111124-01 Burner Retainer Spring 1
5 107486-01 107485-01 107486-01 107485-01 ODS Pilot 1
6 099387-09 099387-09 099387-09 099387-09 Pilot Tube 1
7 098249-01 098249-01 098249-01 098249-01 ODS Nut 2
8 M11084-38 M11084-38 M11084-38 M11084-38 Screw, HWH AB 8-18 x .38 2
9 M11084-26 M11084-26 M11084-26 M11084-26 Screw, HWH AB 10-16 x .38 10
10 ** ** ** ** Chamber Floor 1
11 097809-02 097809-02 097809-02 097809-02 Male Fitting 1
12 098867-10 098867-14 098867-10 098867-14 Gas Regulator 1
13 108628-02 108628-02 108628-02 108628-02 Inlet Tube 1
14 102394-02 102394-02 102394-02 102394-02 Control Bracket 1
15 098522-13 098522-12 098522-13 098522-12 Thermostat Gas Valve 1
16 101381-01 101381-01 101381-01 101381-01 Valve Cover with Piezo 1
17 101628-03 101628-03 101628-03 101628-03 Flexible Connector 1
18 099211-01 099211-01 099211-01 099211-01 Screw, HWH AB 10-16 x 2.50 2
19 098544-01 098544-01 098544-01 098544-01 Thermobulb Clip 1
20 098271-10 098271-10 098271-10 098271-10 Ignitor Cable 1
21 111138-01 111138-01 111138-02 111138-02 Log Set 1
PARTS AVAILABLE — NOT SHOWN
901056-01 901056-01 901056-01 901056-01 Brass Flare Adapter Fitting 1
103470-01 103470-01 103470-01 103470-01 Hardware Pack 1
100563-01 100563-01 100563-01 100563-01 Warning Plate 1
101054-01 101054-01 101054-01 101054-01 Lighting Instruction Plate 1
** Not a field replacement part
