www.desatech.com 111244-01C 35
KEY PART NUMBERS
NO. FDCF Models VDCF Models CDCF Models DESCRIPTION QTY.
1 ** ** ** Outer Casing Top 1
2 ** ** ** Baffle 1
3 ** ** ** Outer Casing 1
4 104281-02CK 104281-02CK 104281-02CK Firebox Hood 1
5 ** ** ** Firebox Top 1
6 ** ** ** Firebox Wrapper 1
7 110339-01CK 110339-01CK 110339-01CK Outer Base 1
8 102635-02 102635-02 102635-02 Front Left and Right Sides 2
9 103209-01 103209-01 103209-05 Extruded Louver 2
10 098304-01 098304-01 098304-01 Screw, PPH AB 10-16 x .38 8
11 M10908-2 M10908-2 M10908-2 Screw, SLTD HWH TPG 6-32 x .38 4
12 104313-01 104313-01 104313-01 Right Pin Hinge 1
13 104313-02 104313-02 104313-02 Left Pin Hinge 1
14 103295-05CK 103295-05CK 103295-03CK Screen Frame 1
15 111038-02 111038-02 111038-02 Remote/Blower Bracket 1
16 M11084-26 M11084-26 M11084-26 Screw, HEH AB 10-16 x .38 35
17 111633-01 111633-01 111633-01 Box Cover 1
18 111200-01 111200-01 111200-01 Support Bracket 1
19 099230-02 099230-02 099230-02 Screw, HWH SHLDR AB 10 x .63 14
** Not a field replacement part
PARTS LIST
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 42 of this manual.
