User’s Manual for SPRO Network Control Host Series
2.4 System Connection Diagram
In SPRO series, there are two types of classic
connections. The connection of SPRO-CAV801 is
similar
with
that
of
SPRO-CAV802.
SPRO-CON9000 is similar with SPRO-CON9100
and SPRO-CON9200.
2.4.1 SPRO-CAV802 System Connection
2.4.2 SPRO-CON9200 Connection Diagram
2.4.2
SPRO-CON9200
System
Connection
