14 CR-iMAX901HD Multiple Signals Scaler User Manual
Common-mode
rejection ratio(CMRR)
>75dB@:20 Hz ~ 20 kHz
Signal type stereo
Impedance input:>10 kΩ(Unbalanced)
maximum input level +19.5dBu,
Gain error ±0.1dB @ 20 Hz ~ 20 kHz
Control types
button
Front panel, LCD screen status display
serial control interface RS-232,9-pin female D-type interface
Baud rate and protocol Baud rate:115200,Data bits:8 bits,stop bits:1,No parity
The serial control port
structure
2=TX,3=RX,5=GND
Ethernet control
interface
RJ-45 female interface
Ethernet control
protocol
TCP/IP
Ethernet control rate Adaptive 10M/100M,full-duplex or half-duplex
HDBaseT remote HDBaseT remote RS232 control
Specification
Power supply
100VAC~240VAC,50/60Hz
Temperature Storage and operation temperature:-20°~+70°C
Humidity Storage and operation humidity:0 ~.95%
Chassis Size 483(L)X230(W)X44mm(H)
Product weight About 2.3kg
MTBF 30,000 hours
Warranty 1 year free warranty and lifetime maintenance
