12 CR-iMAX901HD Multiple Signals Scaler User Manual
Chapter Four Specifications
model
Technical
Specifications CR-iMAX901HD
Analog CV video/YPbPr video
Gain
0dB
Bandwidth 150MHz @ -3dB
Format NTSC,PAL,SECAM
Differential phase
error
0.1°,3.58-4.43 MHz
Differential gain error 0.1%,3.58-4.43 MHz
Switching speed 200 ns(the maximum time)
Signal type Composite video(CVBS), Component video(YPbPr/YCbCr)
Interface RCA female joint(4PIN),1(CVBS),1(YPbPr/YCbCr)
Minimum / maximum
level
Analog signal: -2V/+2V
Impedance 75 Ω
Return loss <-30dB@5MHz
Analog VGA video
Gain
0 dB
Bandwidth 380 MHz
Signal type VGA
Interface 15-pin HD female interface,2 VGA input
Signal strength 0.63V p-p to 0.9 V p-p
Impedance 75 Ω
Return loss <-40dB@5MHz
DC compensation Maximum ±5mV
Supported resolution
640x480@60Hz;800x600@60Hz;1024x768@60Hz;1280x720@60Hz;1280x
800@60Hz;1280x960@60Hz;1280x1024@60Hz;1360x768@60Hz;1366x76
8@60Hz;1400x1050@60Hz;1440x900@60Hz;1600x1200@60Hz;1680x105
0@60Hz;1920x1080@50Hz;1920x1080@60Hz;1920x1200@60Hz
HDMI video
Supported protocols
HDMI1.3a,DVI1.0,HDCP1.3
Maximum pixel clock 225MHz
Interface bandwidth 6.75Gbps(RGB:2.25 Gbps/per lane)
Signal type In HDMI 1.3a / DVI 1.0 specifications HDMI / DVI-D all-digital T.M.D.S. signal
Interface HDMI-A interface (Type A connector ),3 HDMI input,1HDMI output
Minimum / maximum
level
T.M.D.S.2.9V/3.3V
