9 CR-iMAX901HD Multiple Signals Scaler User’s Manual
Chapter Three Code Instructions
Serial protocol:Baud rate:115200 Data bits:8 Stop bits:1 Parity bit:none
Ethernet:Agreement :TCP,IP:192.168.1.190 PORT:6666
Video Switch Command
Command Response Description
S SOURCE 0. >SOURCE CV CV INPUT
S SOURCE 1. >SOURCE YPbPr YPbPr INPUT
S SOURCE 2. >SOURCE VGA1 VGA1 INPUT
S SOURCE 3. >SOURCE VGA2 VGA2 INPUT
S SOURCE 4. >SOURCE HDMI1 HDMI1 INPUT
S SOURCE 5. >SOURCE HDMI2 HDMI2 INPUT
S SOURCE 6. >SOURCE HDMI3 HDMI3 INPUT
S SOURCE 7. >SOURCE DisplayPort DisplayPort INPUT
S SOURCE 8. >SOURCE HDBaseT HDBaseT INPUT
R SOURCE. >Video Input: YPbPr Read Current Video input
Audio Switch Command
Command Response Description
S AUDIO 0. >AUDIO 1 INPUT AUDIO 1 INPUT
S AUDIO 1. >AUDIO 2 INPUT AUDIO 2 INPUT
S AUDIO 2. >AUDIO 3 INPUT AUDIO 3 INPUT
S AUDIO 3. >AUDIO 4 INPUT AUDIO 4 INPUT
S AUDIO 4. >AUDIO 5 INPUT AUDIO 5 INPUT
S AUDIO 5. >AUDIO 6 INPUT AUDIO 6 INPUT
S AUDIO 6. >AUDIO 7 INPUT AUDIO 7 INPUT
S AUDIO 7. >AUDIO 8 INPUT AUDIO 8 INPUT
S AUDIO 8. >AUDIO 9 INPUT AUDIO 9 INPUT
S AUDIO 9. >HDMI&HDBaseT AUDIO INPUT
HDMI&HDBaseT Audio Input for
Video is HDMI&HDBaseT
R AUDIO. >Audio Input: AudioAnalog 1 Read Current Audio Input
Resolution Command
Command Response Description
S OUTPUT 0! >OUTPUT 640x480@60Hz Resolution Output 640x480@60Hz
S OUTPUT 1! >OUTPUT 800x600@60Hz Resolution Output 800x600@60Hz
S OUTPUT 2! >OUTPUT 1024x768@60Hz Resolution Output 1024x768@60Hz
S OUTPUT 3! >OUTPUT 1280x720@60Hz Resolution Output 1280x720@60Hz
S OUTPUT 4! >OUTPUT 1280x800@60Hz Resolution Output 1280x800@60Hz
S OUTPUT 5! >OUTPUT 1280x960@60Hz Resolution Output 1280x960@60Hz
S OUTPUT 6! >OUTPUT 1280x1024@60Hz Resolution Output 1280x1024@60Hz
