Contemporary Control Systems BASremote Installation Guide - Manual (Page 3)

TD040300-0II
3
SPECIFICATIONS
Electrical
(± 10%)
BASR-8M/P BASR-8M BASR-8X
DC AC DC AC DC AC
Input voltage: 48 V N/A 24 V 24 V 24 V 24 V
Input power:
10 W N/A 10 W 17 VA 8 W 17 VA
Input frequency: N/A N/A N/A 47–63 Hz N/A 47–63 Hz
(All modules intended for use with Class 2 circuits.)
Loop Supply +24 VDC, 150 mA max +24 VDC, 150 mA max
Communications
BACnet/IP or Modbus TCP:
ANSI/IEEE 802.3, N/A
10BASE-T/100BASE-TX
Ethernet Data Rates: 10/100 Mbps N/A
Modbus Serial:
Modbus Master Serial ASCII or RTU N/A
2-wire, non-isolated EIA-485
2.4, 4.8, 9.6, 19.2, 38.4, 57.6, 115.2 kbps
100 m max segment length
Expansion Bus:
N/A Proprietary protocol
100 m max segment length
Protocol Compliance
BACnet/IP:
ASHRAE 135-2004, Annex J N/A
B-ASC Profile
Modbus TCP: Modbus Appl. Protocol Spec. V1.1b N/A
Dec. 28, 2006 (modbus.org)
Modbus Messaging on TCP/IP Impl. Guide V1.0b
Oct. 24, 2006 (modbus.org)
Modbus Serial: Modbus over Serial Line Spec. and N/A
Implementation Guide V1.02b
Dec. 20, 2006 (modbus.org)
Regulatory Compliance
RoHS, CE Mark
