6
Chapter 1. SYSTEM OPERATION
This section contains instructions for operating the XPA-200-OD outdoor SSPA. The
primary customer interface to the XPA is via the Remote Communications port. This
section defines in detail the customer interface.
1.1 C
ONNECTOR
J3: AC
P
OWER
, M
AINS
, 205
TO
240 VAC.
Table 1. Connector J3 Pinout
Pin Mating Connector Type
A Ground
B L2
C L1
1.2 C
ONNECTOR
J6: COMM,
R
EMOTE COMMUNICATIONS PORT
.
Mating connector: ITT: KPT06J14-19P or MS3116J14-19P connections, see Table 2.
Table 2. Connector J6 Pinout
Pin Outdoor SSPA
A RS485_+RX
B RS485_-RX
C RS485_+TX
D RS485_-TX
E RS232_RD
F Analog_Pwr_Mon
G RS232_TD
H Aux_In
J Aux_Out
K SumFLT_COM
L SumFLT_NO
M SumFLT_NC
N GND
P ONLINE_Status
R +24V
S Mute
Control
T Minor_FLT_COM
U Minor_FLT_NO
V Minor_FLT_NC
