XPA-200-OD Revision 1
Customer Commands MN/XPA200OD.IOM
20
Command
(Instruction
Code and
qualifier)
Arguments for
Command or
Response to
Query
Description of arguments
(note that all arguments are ASCII numeric
codes, that is, ASCII codes between 48 and 57)
Response to
Command
(target to controller)
Query
(Instruction
Code and
qualifier)
Response to
query
(target to
controller)
Concise
Maintenance
Status
N/A 84 bytes numeric Query only.
Used to Query the Maintenance status of the unit
in concise format. Response is comma delimited.
Example: CMS=aaa.a,bbb.b,ccc.c,ddd.d,eee.e,
fff.f,ggg.g,hhh.h,iii.i,jjj.j,kkk.k,lll.l,mmm.m,nnn.n,
’cr’’lf’
where:
aaa.a = +24V Power Supply
bbb.b = +15V Power Supply
ccc.c = +10V-1 Power Supply
ddd.d = +10V-2 Power Supply
eee.e = +7.5V Power Supply
fff.f = +5V Power Supply
ggg.g = -5V Power Supply
hhh.h = Fan #1 speed (in percent)
iii.i = Fan #2 speed (in percent)
jjj.j = Amplifier temperature in deg. C
kkk.k = Ampifier 10V1
lll.l = Amplifier 10V2
mmm.m=Forward RF output power, in dBm
Note: nnn.n will appear for Ref Voltage if
Reference Osc Module is installed.
N/A CMS? CMS=x….x
(see description
for details of
arguments)
Retrieve
Utility Status
N/A 27 bytes, alpha-
numeric
Query only.
Used to Query the utility status of the unit
Example: RUS=’cr’
ADR=0001’cr’
BDR=9600’cr’
N/A RUS? RUS=x….x
(see description
for details of
arguments)
Concise
Utility Status
N/A 11 bytes, alpha-
numeric
Query only.
Used to Query the Maintenance status of the unit,
response is comma delimited.
Example: CUS=aaaa,bbbb,ccc,’cr’’lf’
where:
aaaa = Remote Unit Address
bbbb = Remote Baud Rate
N/A CUS?
CUS=x….x
(see description
for details of
arguments)
