XPA-200-OD Revision 1
Customer Commands MN/XPA200OD.IOM
19
Command
(Instruction
Code and
qualifier)
Arguments for
Command or
Response to
Query
Description of arguments
(note that all arguments are ASCII numeric
codes, that is, ASCII codes between 48 and 57)
Response to
Command
(target to controller)
Query
(Instruction
Code and
qualifier)
Response to
query
(target to
controller)
Circuit
Identification
CID= 24 bytes,
alpha-numeric
Command or Query
Used to identify or name the unit or station. First
line is limited to 12 characters. Second line is also
limited to 12 characters. No carriage return
between first line and second line.
Example: CID=’cr’
--Earth Station 1—
---SSPA #1---- CID= (message ok)
CID? (received ok, but
invalid arguments
found) CID? CID=x…x
(see description
for details of
arguments)
Retreive
Firmware
Number
N/A Query only
Gets the Firmware Number of the unit.
Example: <1/FRW=
>0001/FRW/10786’cr’
BULK=FW/10786’cr’
MnC=FW/10787’cr’
FPGA=FW/10788’cr’’lf’
N/A FRW? FRW=FWxxxxx
Retrieve
Maintenance
Status
N/A 168 bytes,
alpha- numeric
Query only.
Used to Query the maintenance status of the unit
P24VT=024.1’cr’
P15VT=015.2’cr’
P10V1=010.4’cr’
P10V2=010.4’cr’
P7V5T=007.8’cr’
P5VLT=005.8’cr’
N5VLT=-05.7’cr’
FANR1=100.0’cr’
FANR2=100.0’cr’
ATEMP=+40.0’cr’
A10V1=010.2’cr’
A10V2=010.2’cr’
FWPWR=+37.6’cr’
RVPWR=02.0’cr’’If’
*Note: REFV will appear if REF OSC module is
installed.
N/A RMS? RMS=x….x
(see description
for details of
arguments)
