XPA-200-OD Revision 1
Customer Commands MN/XPA200OD.IOM
21
Command
(Instruction
Code and
qualifier)
Arguments for
Command or
Response to
Query
Description of arguments
(note that all arguments are ASCII numeric
codes, that is, ASCII codes between 48 and 57)
Response to
Command
(target to controller)
Query
(Instruction
Code and
qualifier)
Response to
query
(target to
controller)
Retrieve
Alarm Status
N/A 117 bytes,
alpha-numeric
Query only.
Used to Query the Alarm status of the unit
Example: RAS=’cr’
P24VT=OK’cr’
P15VT=OK’cr’
P10V1=OK’cr’
P10V2=OK’cr’
P7V5T=OK’cr’
P5VLT=OK’cr’
N5VLT=OK’cr’
FAN#1=OK’cr’
FAN#2=OK’cr’
HSTMP=OK’cr’
SHTDN=OK’cr’
IICST=OK’cr’
FPOUT=OK’cr’’IF’
N/A RAS?
RAS=x….x
(see description
for details of
arguments)
Concise
Alarm Status
N/A 25 bytes,
numeric with
commas
Query only.
Used to Query the Alarm status of the unit,
response is comma delimited.
Example: CMS=a,b,c,d,e,f,g,h,I,j,k,I,m’cr’’lf’
where: a thru k = 0 or 1, 0 = OK 1 = FT
a = +24V Power Supply
b = +15V Power Supply
c = +10V-A Power Supply
d = +10V-B Power Supply
e = +7.5V Power Supply
f = +5V Power Supply
g = -5V Power Supply
h = Fan#1 State
i = Fan#2 State
j = Heatsink Temp
k = Shutdown
l = llC Status
m=Forward Power Alarm
N/A CAS?
CAS=x….x
(see description
for details of
arguments)
