XPA-200-OD Revision 1
Customer Commands MN/XPA200OD.IOM
22
Command
(Instruction
Code and
qualifier)
Arguments for
Command or
Response to
Query
Description of arguments
(note that all arguments are ASCII numeric
codes, that is, ASCII codes between 48 and 57)
Response to
Command
(target to controller)
Query
(Instruction
Code and
qualifier)
Response to
query
(target to
controller)
Retrieve
Configuration
Status
N/A 45 bytes, alpha-
numeric
Query only.
Used to Query the configuration status of the unit
Example: RCS=’cr’
ATT=12.75’cr’
AMP=1’cr’
MUT=1’cr’
ONL=1’cr’
RED=1-1’cr’
GOF=00.00’cr’
AFR=1’cr’’lf’
where:
ATT= attenuation in dB
AMP= RF power amplifier state, 0=OFF, 1=ON
MUT=RF mute state, 0=unmuted, 1=muted
ONL=Online status for redundancy
RED=Redundancy state and mode,
states: 0=OFF, 1=ON,
modes: 0 = auto, 1 = manual
GOF=Gain Offset in dB
AFR= auto fault recovery, 0=manual, 1=auto
N/A RCS?
RCS=x….x
(see description
for details of
arguments)
Concise
Configuration
Status
N/A 24 bytes,
numeric
Query only.
Used to query the summarized version of RCS.
Example: CCS=aaaaa,b,c,d,e-e,fffff,g,‘cr’
Where:
aaaaa = attenuation in dB
b = RF power amplifier state
c = mute state, 0 = unmuted, 1 = muted
d = online status
e-e = redundancy state and mode
fffff = gain offset in dB
g = AFR N/A CCS? CCS=x….x
(see description
for details of
arguments)
