Chapter 12. Stored Events & Alarms
Total New Events: The number of events that have occurred since last viewing the stored events
log.
XSAT Indicator Field: This field to the
immediate right of the Stored Events number
displays the Currently Selected XSAT. This is a
status only and the Currently Selected XSAT
cannot be changed in this menu.
Retrieve Next 5 Events: This (OK) button will
update the Event display with up to the next 5
events.
Event Window: Where the stored events are
displayed and updated.
Clear Event Log: Will erase any events in the
event log and provide a clear display as shown
in Fig. 12.1.
Reset Event Pointer: This (OK) button will
reset the event pointer to the top of the event list
to show the start of the event log.
(GET DATA) button: This button will refresh
the Event Window with any new event data.
Figure 8
