Fast Ethernet Switching System User’s Guide
Web Management
91
System Configuration
The System Information panel is the first panel you see when logging into the
DES-5200 for web management.
Select folders to view their contents. Select an option to move to that panel.
System Configuration
The System configuration panel shows general information about the DES-5200
and enables you to assign a LAN IP Address, Subnet Mask, LAN Default
Gateway and contact information on the system administrator.
User Account Management
The User Account Management menu enables you to add users, delete users and
modify user account information.
Switch Port Configuration
The Switch Port Configuration menu enables you to configure individual ports.
You can set the speed, duplex mode, enable and disable ports and make other
changes. The panels and options may be different, depending on the DES-5200
model you purchased and the modules you have installed. Refer to Module
Configuration, at the end of this chapter, for an explanation of the differences
between the modules.
Spanning Tree Configuration
The menu enables you to enable or disable Spanning Tree Algorithm, set the
Bridge Priority, Hello Time, Forward Delay Time and Max Age Time.
SNMP Management Configuration
The SNMP Management Configuration menu enables you to create SNMP
Communities and configure SNMP Trap Manager Settings.
VLAN Port Management
The VLAN Port Management menu enables you to create, delete, and modify
VLANs quickly and easily.
Trunking Port Management
The Trunking Port Management menu enables you to create, delete and modify
Trunking Ports quickly and easily.
