3
Installations using Adapter Cable Digital Inputs
If you are using the adapter cable digital inputs in your installation, the
following additional tools and other items may also be required:
• Crimping Tool
• Multimeter
• Fuse Tap - Required to obtain +12 V from the fuse panel.
Planning the Installation
Installation of theDriveRight OBD is simple. Unless you are using the
two digital inputs on the adapter cable, you only need to plug the OBD
cable into your vehicle’s OBDII port and then install the DriveRight
console.
The digital inputs on the DriveRight 600 E adapter cable may be used to
monitor any 12 VDC electrical device or accessory in the vehicle, but
they are typically used for monitoring accessories like the brake lights,
headlights, or seat belts.
To install DriveRight OBD:
1. Plug the OBD cable into your vehicle’s OBDII port.
2. Connect the digital inputs (if used).
3. Install the DriveRight console in the vehicle.
4. Test the DriveRight installation.
