Electrical characteristics curves – Delta Electronics S36SS User Manual
Page 5
ELECTRICAL CHARACTERISTICS CURVES
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
0.0
2.0
4.0
6.0
8.0
LOAD CURRENT (A)
O
U
T
P
U
T
VO
LT
AG
E (
V
Vin=48V
Figure 11:
Output voltage vs. load current showing typical
current limit curves and converter shutdown points.
5
Strip
Copper
Vo(-)
Vo(+)
10u
1u
SCOPE
RESISTIVE
LOAD
Figure 9
:
Output voltage noise and ripple measurement test
setup. Scope measurement should be made using a BNC
cable (length shorter than 20 inches). Position the load
between 51 mm to 76 mm (2 inches to 3 inches) from the
module.
Figure
10:
Output voltage ripple at nominal input voltage and
rated load current (20 mV/div). Load capacitance: 1
µ
F ceramic
capacitor and 10
µ
F tantalum capacitor. Bandwidth: 20 MHz.
