Desa (V) CB36(N - Manual (Page 31)

30
www.desatech.com 117437-01
PARTS LIST
Models (V)CB36N, (V)CB36P
KEY
NO.
(V)CB36N (V)CB36P DESCRIPTION QTY.
1 116317-01 116317-01 Remote Ignitor Bracket 1
2 108085-01 -- Pilot Orifice #51(Natural Gas) 1
-- 108085-02 Pilot Orifice #30 (Propane/LP Gas) 1
3 117507-01 -- Pilot Assembly (Natural Gas) 1
-- 117507-02 Pilot Assembly (Propane/LP Gas) 1
4 117702-01 -- Burner Orifice #45 (Natural Gas) 1
-- 26482 Burner Orifice #55 (Propane/LP Gas) 1
5 26808 26808 Valve Bracket 1
6 24389 24389 Tube 3/8" Dia. x 11" Aluminum 1
7 24360 24360 Pilot Bracket 1
8 14500 14500 Fitting 3/8" MPT x 1/2” Flare 1
9 14399 14399 Fitting Brass Elbow 3/8" MPT x 3/8" Comp. Tube 1
10 14396 14396 Fitting Brass Straight 3/8" MPT x 3/8” Comp. Tube 1
11 14512 -- Gas Control Valve Millivolt (Natural Gas) 1
11 -- 14513 Gas Control Valve Millivolt (Propane/LP Gas) 1
12 14299 14299 Air Shutter 1
13 14261 14261 Ignitor Piezo 1
14 11226 11226 Washer, Flat 7/8" ID x 2" OD x 1/8" Thick 2
15 11214 11214 Fitting Bulkead w/ Nut Brass 1
16 11187 11187 Screw, #8 x 1/4" PPH 1
17 11107 11107 Screw, #10-32 x 1/4" PPH Zinc 4
18 11105 11105 Screw, #10 x 1/2" HWH LGM Zinc 10
19 11102 11102 Screw, #8 x 3/8" PPH F Zinc. 2
This list contains replaceable parts used in your fi replace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 26 of this manual.
PARTS LIST
BURNER ASSEMBLY FOR MODELS
(V)CB36N, (V)CB36P
