PARTS LIST
Models (V)CB36N, (V)CB36P, (V)CB36NE, (V)CB36PE
PARTS LIST
FIREPLACE ASSEMBLY FOR MODELS
(V)CB36N, (V)CB36P, (V)CB36NE, (V)CB36PE
This list contains replaceable parts used in your fi replace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 26 of this manual.
KEY
NO. (V)CB36N
(V)CB36P (V)CB36NE
(V)CB36PE
DESCRIPTION QTY.
1 116108-01 116108-01 Log Set 1
1-1 116109-01 116109-01 Burner Base Log 1
1-2 116110-01 116110-01 Rear Log 1
1-3 111802-05 111802-05 Right Top Log 1
1-4 111802-04 111802-04 Left Top Log 1
2 117447-01 117447-01 Burner Assembly Complete (See pages 30 and 32) 1
3 ------ 114889-01 Junction Box Duplex Plug 1
4 106967-01 106967-01 Damper Assembly 1
5 117461-01 117461-01 Vent Baffle 1
6 117456-01 117456-01 Diverter Panel 2
7 117455-01 117455-01 Heat Deflector 1
8 114875-02 114875-02 Fireplace Surround 1
9 117450-01 117450-01 Wire Harness Assembly 1
10 117451-01 117451-01 Fireplace Top 1
11 117452-01 117452-01 Fireplace Top Insulation 1
12 117445-01 117445-01 Louver Assembly 2
13 117458-01 117458-01 Hanger Bracket 1
14 117446-01 117446-01 Glass Door Assembly 1
15 117442-01 117442-01 Face Assembly 1
16 117439-01 117439-03 Firebox Assembly Complete (Natural Gas) 1
16 117439-02 117439-04 Firebox Assembly Complete (Propane/LP Gas) 1
17 110973-01 110973-01 Cover Junction Box 2
18 106543-01 106543-01 High Limit Switch 1
19 26782 26782 Screen Assembly 2
20 26290 26290 Firebox Leg 2
21 24460 24460 Gas Conduit Assembly 2
22 21171 21171 Gas Knock-Out Cover 2
23 20090 20090 Spring Clip 2
24 ------ 14418 Duplex Plug Receptacle 1
25 ------ 14123 Bushing Universal Strain Relief 1
26 11408 11408 Bushing 0.5" Electric 3
27 11404 11404 Cable Tie Down 1
PARTS AVAILABLE - NOT SHOWN
25580 25580 Ember Bag Assy 1
27253 27253 Notice Label 1
117700-01 117701-01 Wiring Diagram Label 1
