Figure 7. MVC 236 Operational Test Connections
120 Vac, 100 W
MVC 236
240 F– F+ 120 60 TAP 24 23 TB2
120 Vac
Source
32 100/200 63 125 16 15 14 50/100 COM COM TB1
Voltage Adjust Field Voltage Frequency
Jumper for input
frequency used
See steps 2, 6, and 9
of Operational Test.
