26
Solid beep for 1/3 of a stitch cycle,
no beep for the rest of the cycle.
Main
Sound
Back
Mute Max
Overspeed Alarm
Off
On
V o l u m e
50%
When the bobbin runs out, press the square Stop
Recording button and note how many yards is indi-
cated under the Bobbin Thread Capacity (Figure 33),
perhaps 210 yards. Since you want a warning as to
when the bobbin is getting low, use the “-” button to
specify a lower number, such as 195 yards. Save that as
one of the Bobbin Thread Capacity Presets. You might
want to make a note as to which type of thread the pre-
set represents. Put a new bobbin with the same thread
into the machine and press the New Bobbin button.
Then press the Alarm button. As you quilt, the remain-
ing bobbin thread value will estimate how much thread
remains on the current bobbin, and when you reach
the capacity value, an alarm will sound warning you
that your bobbin is nearly out of thread (Figure 34).
When operating in Manual mode, the low bobbin
function assumes you will stitch at approximately the
last SPI setting you had on the regulated screen. If the
SPI setting was below 8 stitches per inch, the function
will assume you will quilt at 10 stitches per inch. It
is advisable therefore to set the stitches per inch that
you will be quilting on the regulated screen before you
change to manual mode.
You can store three Bobbin Thread Capacity preset
values – one for each of three different types of thread.
Simply go through the record process with a full bob-
bin of that type of thread and then store the capacity as
a preset. When you switch to using that type of thread,
press appropriate preset button. Insert a full bobbin
with that type of thread, press New Bobbin, and all of
the settings will be based on that type of thread.
Sound Screen
The “Volume” portion of this screen has two buttons
and a sliding control. Pressing on the “Mute” button
turns the alarm volume off. Pressing the “Max” button
turns the volume to its loudest level. Pressing the slid-
ing control in any position sets the volume to the level
indicated in that control. Pressing and moving back
and forth across the sliding control will change the
volume up as it is moved left to right and down as it is
moved from right . The Over-Speed Alarm box allows
the user to turn the alarm on and off. (Figure 35)
Press the “Main” button to return to the “Regulated” or
“Manual” menu screen or the “Back” button to return
to the “More” menu screen.
Figure 35
Figure 33
Solid beep for 1/3 of a stitch cycle,
no beep for the rest of the cycle.
Main
Low Bobbin
Back
Bobbin Thread Capacity
Remaining Bobbin Thread
Bobbin Thread Capacity Presets
100.0 Yards
100.0 Yards New Bobbin
100.0 130.0 200.0
Figure 34
Solid beep for 1/3 of a stitch cycle,
no beep for the rest of the cycle.
Main
Low Bobbin
Back
Bobbin Thread Capacity
Remaining Bobbin Thread
Bobbin Thread Capacity Presets
100.0 Yards
100.0 Yards New Bobbin
100.0 130.0 200.0
