21
Using the Touch Screen
Displays on the Handlebars
Figure 18
Stitch Mode
More
Up
Down
Needle Stop
Manual 58 %
Regulated
Speed
Presets
Manual
30%
50%
70%
Stitch Mode
More
Up
Down
Needle Stop
Regulated 11 SPI
Regulated
SPI
3%
SR Style
Manual
Precision
Cruise
The Baby Lock Crown Jewel II has touch-screen dis-
plays on the front and rear handlebars. Settings may
be changed at either of these locations.
Main Screen
Manual Mode Screen
Button Functions:
Pressing the “Regulated” button while in the Manual
Mode Screen will toggle to the Regulated Mode
Screen. The current Stitch Mode is displayed at the
top left corner of the screen. Different options are
available depending upon which mode the system is
in. (Figure 18)
Needle Stop
When in “Needle Up” mode (the radio button is white
when activated), the needle ends in the “Up” position
upon pressing the “Stop” button on the handles. This
button does not move the needle, but simply deter-
mines the final needle position after the machine has
been stopped. (Figure 19)
When in “Needle Down” mode (the radio button is
white when activated), the needle ends in the “Down”
position upon pressing the “Stop” button on the
handles. Again, this button does not move the needle,
but sets the final resting position of the needle after
“Stop” is pressed.
Figure 19
