Names of battery parts and their functions
1 DC IN connector
Connect the power adapter to recharge.
2 Battery knob
Twist to lock / unlock the battery pack.
3 Battery indicator LED.
When the battery is discharging, LED is off.
When recharging the battery, LED is red.
When the LED is green, recharge is finished.
4 Player terminals
Supply power to the player.
CAUTION:
Do not short-circuit the terminals.
