Multi Format LCD Monitor 31

6. Other Functions

2. Use the UP/DOWN button to select desired

input source and press the ENTER button to

confirm.

3. Input signal resolution displays on the bottom

of OSD menu.

4. Press ANALOG button again to remove the

OSD menu from display.

5. Menu will be disappeared when time set is

over from the screen

When using ANALOG mode, always check the

input method and modify the setting as needed

for optimized output results.

This product is capable of processing all

input signals usable in ANALOG mode. The

ANALOG input settings are as follows:

1. Press ANALOG button on the front of the

product and activate the menu below.

This product supports various scan

modes.

Press [SCAN] button on the front of the

monitor to activate different scan modes.

1. Press [SCAN] button continuously to activate

various scan modes.

- OVER SCAN -> ZERO SCAN -> UNDER SCAN

-> 2:1 SCAN -> 1:1 SCAN -> FIT WIDTH -> USER

ASPECT

2. Scan mode types are differed by connected signal.

- SDI, COMPONENT, RGB : OVER SCAN -> ZERO

SCAN -> UNDER SCAN -> 2:1 SCAN -> 1:1 SCAN

-> FIT WIDTH -> USER ASPECT

- DVI ANALOG, DVI DIGITAL, HDMI : OVER

SCAN -> ZERO SCAN -> 2:1 SCAN -> 1:1 SCAN

-> USER ASPECT

- COMPOSITE 1/2/3, S-VIDEO : OVER SCAN ->

ZERO SCAN -> 2:1 SCAN -> 1:1 SCAN -> USER

ASPECT

[2] SCAN

[1] ANALOG

COMPOSITE 1

COMPOSITE 2

COMPOSITE 3

S-VIDEO

COMPONENT

RGB

DVI ANALOG

DVI DIGITAL

HDMI

NO VIDEO
