LQM-241W
Product Specification
* Above specifications may be changed without notice
** SMPTE-372M mode is an optoin
24” I
nt
eg
ra
te
d m
ul
ti f
orma
t HD Q
uad in
pu
t mo
ni
to
rs
24
Input
1 x DVI- I DVI IN
3 x BNC Analog Input
4 x BNC SDI A/B/C/D Channel Input
1 x HDMI HDMI Input
Output
3 x BNC Analog Output
4 x BNC SDI A/B/C/D Channel (Active Through Out)
Input Signal
Analog Composite / S- Video / Component / RGB
HD - SDI 1.458Gpbs
SD - SDI 270Mpbs
DVI VESA/IBM Modes
HDMI 480i/480p/720p/1080i & VESA/IBM Modes
Analog Input Spec
Composite 1.0Vpp (With Sync)
S- Video 1.0Vpp (Y With Sync), 0.286Vpp(C)
Component 1.0Vpp (Y With Sync), 0.7Vpp (Pb,Pr)
RGB 1.0Vpp (G With Sync), 0.7Vpp (B,R)
SDI Input Signal
Formats
SMPTE - 274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE - 296M 720p (60/59.94/50)
SMPTE - 260M 1035i (60/59.94)
SMPTE - 125M 480i (59.94)
ITU - R BT.656 576i (50)
Audio In Embedded Audio / Analog Stereo (Phone Jack)
Audio Out Analog Stereo (Phone Jack) / SPEAKER (Stereo)
LCD
Size 24”
Resolution 1920 x 1200 (16:10)
Pixel Pitch 0.270(H) x 0.270(W) mm
Color 16.7M(true 8bit)
Viewing Angle H : 178 degrees / V : 178 degrees
Luminance of white 500 cd/㎡(Center)
Contrast 800:1
Display Area 518.4(H) x 324.0(V) mm
Power 24V DC / AC100~240V
Power Consumption (Approx.) 77 Watts(DC / Typ.)
Operating Temperature 0℃to 40℃(32℉ to 104℉)
Storage Temperature -20℃to 60℃(-4℉to 140℉)
Main Body Dimensions (mm/inch) 552.5 x 389 x 95 (21.73 x 15.31 x 3.74)
Main Body Dimensions (With Stand) 586 x 417 x 150 (23.07 x 16.41 x 5.90)
Weight 11Kg / 24.2 lb
Accessory AC Power cord, Manual
Option Carrying Case, 19” Rack Mountable Kit, ND Filter
