4. Specification of Receiver
Parameter Symbol Min. Typ. Max. Unit Note
Input Optical Wavelength λ
IN
1480 1490 1500 nm PIN-PD
Receiver Sensitivity P
IN
-26 dBm Note (1)
Input Saturation Power (Overload) P
SAT
-3 dBm
Signal Detect -Assert Power P
A
- -26 dBm
Signal Detect -Deassert Power P
D
-44 dBm Note (2)
Signal Detect Hysteresis P
A
-P
D
0.5 2 6 dB
Data Output Rise/Fall time t
r
/t
f
260 ps Note (3)
Receiver
Reflectance
1480 to 1500nm -12 dB Note (4)
1260 to 1360nm -43 dB
1550 to 1560nm -33 dB
Optical Isolation
from External
Source
1640 to 1665nm -33 dB
Note (1). Measured with Light source +1dBm, 1490nm, ER=9dB; BER =<10 -12 @PRBS=2 7 -1 NRZ
This assurance should be met with asynchronous data flowing out of the optical transmitter of
the system under test. The output data pattern from the transmitter of the system under test is a
repetition of alternate 0/1 pattern as defined for this measurement.
Note (2). When SD deasserted, the data output is Low-level (fixed)
Note (3). These are 20%~80% values.
Note (4). Measured at wavelength of 1490nm.
5. Electrical Interface Characteristics
Parameter Symbol Min. Typ. Max. Unit Note
Transmitter
Total Supply Current
I
CC
A mA Note (1)
Differential line input Impedance R
IN
80 100 120 Ohm
Differential Data Input Swing V DT 400 1600 mV
p-p
Data Input Voltage- High V
IH
-V
CC
-1.165 -0.880 V
Data Input Voltage- Low V
IL
-V
CC
-1.810 -1.475 V
LVPECL
BiasCNT Input Voltage- High V
BCH
2 Vcc V
BiasCNT Input Voltage- Low V
BCL
0 0.8 V
LVTTL
Receiver
Total Supply Current
I
CC
B mA Note (1)
Differential Data Output Swing V DR 400 650 900 mV
p-p
Note (2)
Signal Detect Output Voltage-High V
LOSH
2 Vcc+0.3 V
Signal Detect Output Voltage-Low V
LOSL
0 0.8 V
LVTTL
Note (1). A (TX)+ B (RX) = 300mA (Not include termination circuit)
Note (2). Internally AC coupled, but requires a 100Ohm differential termination at or internal to Serializer/
Deserializer.
