Appendix B: VTCB2100 Main Board
a
PPendix
b: vtCb2100 m
ain
b
oard
Specifications
Expansion
• 1 GPS Module
• 1 PCI-104 socket
• 1 Bluetooth module (optional)
• 2 Mini PCI Express socket
- 1 PCIe interface for WLAN module
- 1 PCIe + USB interface for 3.5G module
Storage
• One SATA 2.5” HDD bay
• One SATA DOM
I/O Interfaces - Front
• 4 SMA-type mounting holes for WLAN, HSDPA and Bluetooth
• 1 power button
• 1 reset switch
• 1 SIM card socket
• 2 USB 2.0
• 4 LEDs for Standby, HDD, WLAN/HSDPA and GPO
• 1 line-out
• 1 mic-in
I/O Interfaces - Rear
• Mounting hole reserved:
For RF Coax to SMA Bulkhead x 1 (For GPS) reference, signal connect to
function board
• 8V~60V wide range DC power input, power ignition signal control
• Dual VGA output (Clone mode)
• 5V/1A, 12V/1A DC power output, can be controlled by S/W
• Audio Mic-In x 1, Line-Out x 1
• 2 x RS232 (COM1/2)
• 1 x RS485 (COM3)
• USB 2.0 x 2
• LVDS x 1 (DB26 female connector for LVDS with backlight, control
power (+12V) and USB 2.0 x 1)
• 10/100/1000 Fast Ethernet, RJ45 with LED connector x 1
• GPIO x 1 (4 input & 4 output)
