Appendix A: I/O Address Function
Onboard Module Disable/Enable(1)
I/O port : 0EE6H
Bit Function Description
Bit 0 3.5G module
0: Disable
1: Enable (*)
Bit 1 WLAN module
0: Disable
1: Enable (*)
Bit 2 External +12V power
0: Disable
1: Enable (*)
Bit 3 External +5V power
0: Disable
1: Enable (*)
Bit 4
Bit 5 Wake on RTC module
0: Disable (*)
1: Enable
Bit 6 CAN bus Port
0: Disable
1: Enable (*)
Bit 2, 1, 0: Time Setting
Bit 2~0 Time (sec)
000 1 (*)
001 2
010 4
011 8
100 16
101 32
110 64
111 128
WDT
I/O port : 0EE5H
Bit Function Description
Bit 3 WDT Disable/Enable
0: Disable (*)
1: Enable
Auto clear WDT timer when reading/writing I/O port 0EE5H.
(*) Default setting
