Chapter 4: BIOS Setup
Serial Port 1 Configuration
This section is used to configure serial port 1.
Serial Port
Enables or disables the serial port.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enable or Disable Serial Port
(COM) Serial Port 1 Configuration
Serial Port
Device Settings
[Enabled]
IO=2F8h; IRQ=3;
H/W Monitor
This section is used to monitor hardware status such as temperature, fan
speed and voltages.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
PC Health Status
FAN Setting
Set Temp.-active S.F.
Set Temp.-active full run
Initial FAN speed (S.F. )
CPU Core Temperature(DTS)
CPU FAN Speed
CPU:VCORE
+12V
+5V
+3.3V
[Enable Smart Fan]
[35 C/ 95 F]
[75 C/167 F]
[25 %]
: +54 C
: 2057 RPM
: +0.924 V
: +12.151 V
: +5.008 V
: +3.288 V
FAN Setting
Selects the speed of the fan, the options are Always Full Speed, Enable
Smart Fan or Disable.
Set Temp.-active S.F.
Configures the temperature threshold to activate smart fan.
Set Temp.-active Full Run
Configures the temperature threshold to activate the fan in full speed.
