NTK-AV01 / NTK-AV02 Connectors Pin Definitions
This section provides descriptions, illustrations and pin definitions of the
NTK-AV01 / NTK-AV02 external connectors.
Connector Specification
Pin Definition Pin Definition
A1 LINE_L B1 FRONT_OUT_L
A2 LINE_R B2 FRONT_OUT_R
A3 MIC_JD B3 MIC_L
A4 LINE_JD B4 MIC_R
A5 FRONT_JD B5 AGND
A6 GND B6 AGND
A7 GND B7 GND
A8 GND B8 GND
A9 NC B9 NC
A10 NC B10 NC
A11 GND B11 GND
A12 GND B12 GND
A13 DDI1_TX1N B13 DDI1_TX0N
A14 DDI1_TX1P B14 DDI1_TX0P
A15 GND B15 GND
A16 DDI1_TX3N B16 DDI1_TX2N
A17 DDI1_TX3P B17 DDI1_TX2P
A18 GND B18 GND
A19 DDI1_HPD B19 DDI1_DDC_SCL
A20 NC B20 DDI1_DDC_SDA
A21 GND B21 GND
A22 NC B22 VCC5
A23 NDIK_DET# B23 VCC5
A24 GND B24 GND
A25 NC B25 VCC3
A26 NC B26 VCC3
A27 GND B27 GND
A28 CRT_HSYNC B28 GND
A29 CRT_VSYNC B29 CRT_RED
A30 CRT_DDC_CLK B30 CRT_GREEN
A31 CRT_DDC_DAT B31 CRT_BLUE
A32 GND B32 GND
Top
Bottom
PCIE 4x 64pin Connector
JP1
