5-3 Jumper Settings

Panel Power selection:JP1

Function

JP1 (1-2) (2-3)

◎3V

5V

◎Default setting 1-2 short.

CMOS CLEAR SIGNAL: JP2

Function

JP1 (1-2) (2-3)

◎NORMAL

CLEAR CMOS

◎Default setting 1-2 short.
