Chapter 3: BIOS Setup
PEAK 876VL2/877VL2 User Manual
South Bridge Configuration
This section is used to configure the south bridge features.
BIOS SETUP UTILITY
v02.67 (C)Copyright 1985-2009, American Megatrends, Inc.
← → Select Screen
↑↓ Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
South Bridge Chipset Configuration
USB Functions [Enabled]
EHCI Controller#1 [Enabled]
EHCI Controller#2 [Enabled]
GbE Controller [Enabled]
GbE LAN Boot [Disabled]
GbE Wake Up From S5 [Disabled]
LAN2 Boot [Disabled]
HDA Controller [Enabled]
SMBUS Controller [Enabled]
Restore on AC Power Loss [Power On]
Power-Supply Type [ATX]
PCIE Ports Configuration
PCIE Port 0 [Auto]
PCIE Port 1 [Auto]
PCIE Port 2 [Auto]
PCIE Port 3 [Auto]
PCIE Port 4 [Auto]
PCIE Port 5 [Auto]
PCIE High Priority Port [Auto]
USB Functions
Enables or disables the USB controller.
EHCI Controller#1 and EHCI Controller#2
Enables or disables the Enhanced Host Controller Interface (USB 2.0).
Enable/Disable USB
controller in system.
Chipset
GbE Controller
Enables or disables the Gigabit LAN controller.
GbE LAN Boot
Select Enabled to allow the system to boot from LAN.
GbE Wake Up From S5
Select Enabled to allow the system to wake up from S5 using LAN.
LAN2 Boot
Select Enabled to allow the system to boot via LAN2.
HDA Controller
Enables or disables the HDA controller.
SMBUS Controller
Enables or diasbles the SMBUS controller.
