Chapter 2: Jumpers and Connectors
PEAK 876VL2/877VL2 User Manual
LAN LED Connector
Connector size: 2x4, 8-pin box header, 2.54 mm pitch
Connector location: JP5
1
2
7
8
Pin
Definition
Pin
Definition
1
3V3M_LAN
2
LAN1_LED_LNK#_ACT
3
3V3M_LAN
4
LAN1LINK#
5
3VSB
6
LAN2_LED1
7
3VSB
8
LAN2_LINK#
