Chapter 4: BIOS Setup
SATA Mode
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Select IDE / AHCI / RAID Mode SATA Configuration
SATA Port0
SATA Port1
SATA Port2
SATA Port3
SATA Port4
SATA Port5
SATA Mode
Hitachi HTE545 (160.0
Not Present
TS16GCFX500 (15.8G
Not Present
Not Present
Not Present
[IDE Mode]
[Compatible]
[Enhanced]
SATA Mode
Disabled
IDE Mode
AHCI Mode
RAID Mode
Configures the SATA as IDE, AHCI or RAID mode.
IDE This option configures the Serial ATA drives as Parallel ATA
physical storage device.
RAID This option allows you to create RAID or Intel Matrix Storage
configuration on Serial ATA devices.
AHCI This option configures the Serial ATA drives to use AHCI
(Advanced Host Controller Interface). AHCI allows the storage
driver to enable the advanced Serial ATA features which will
increase storage performance.
Advanced
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Enables Legacy USB support.
AUTO option disables legacy
support if no USB devices are
connected. DISABLE option will
keep USB devices available
only for EFI applications.
USB Configuration
USB Devices:
1 Keyboard
Legacy USB Support
EHCI Hand-off
[Enabled]
[Disabled]
USB Configuration
This section is used to configure the USB.
