Technical Information
LΩGIC™ 1X36 User Manual Rev. 08
28
Technical Specifications
Dimensions and
Weight
Length Width Height Weight
9.8 in (250 mm) 3.9 in (100 mm) 2.0 in (50 mm) 1.95lbs (.88 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Electrical Power Supply Type Range Voltage Selection
Switching (internal) 100~240 V, 50/60 Hz Auto-ranging
Parameter 120 V, 60 Hz 230 V, 50 Hz
Consumption 58 W (0.5 A) 58 W (0.3 A)
Inrush current N/A N/A
Power I/O Input Output
Connectors IEC N/A
Cord plug Edison N/A
Light Source Type Power Lifespan
N/A N/A N/A
Color Quantity Current
Determined by Product N/A N/A
Photo Optic Parameter Optics
Illuminance @ 5 m N/A
Beam angle N/A
Field angle N/A
Thermal Max. External Temperature Cooling System
104° F (40° C) Convection
DMX I/O Connectors Connector Type Channel Range
CAT 5 Sockets 1, 2, 3, 4, 5, 6, 8
Ordering
LΩGIC™ 1X36
31x36001
