Operation
12
LΩGIC™ 1X36 User Manual Rev. 08
AUTO 01~10 are
fully configured
programs and
cannot be modified.
However, CUSTOM
01~10 programs are fully
customizable (see Edit
Custom).
AUTO 01~10
consist of two (2)
different, fully
configured programs
giving the user a total of
twenty(20) different auto
programs to choose from.
Master/Slave
On the Master product:
1. Go to MENU>RUN and select DMX.
2. Go to MENU>AUTO and select any Auto program.
On each of the Slave products:
1. Go to MENU>RUN and select SLAVE.
The slave products will follow the program played by the Master.
Static Colors
1. Go to MENU>STATIC.
2. Select a color or effect RED, GREN, BLUE, DIMM, and STRO.
3. Select a color value [000~255] or a strobe frequency [0~20].
Auto Play
1. Go to MENU>AUTO.
2. Select a program RGB [01~10].
3. Select a speed SP [001~255].
Custom Play
1. Go to MENU>CUSTOM.
2. Select a program CUSTOM [01~10].
Edit Custom
1. Go to MENU>EDIT.
2. Select a program C-[01~10].
3. Select a scene S [01~20].
4. Select a color RED, GREN, or BLUE.
5. Configure the color value [000~255].
6. Repeat steps 4 and 5 for the other colors.
7. Configure the strobe frequency STROB [00~20].
8. Configure the Step and Fade timers [000~255].
9. Repeat steps 4 to 8 for the other scenes.
