Operation
L
ΩGIC™ 1X36 User Manual Rev. 08
15
Programming (SpectraWhite™ Mode)
Refer to the Menu Options section on page 20 to learn how the menu options relate to each
other. The Menu Options section has a Main level and a variable number of programming
levels for each option.
To go to an option in the Main level, press
To select an option or value within the current programming level press or
until it shows on the display. Press to accept it. In this case, if there is another
programming level, you will see its first option. Otherwise, you will see the selected value.
To exit to the previous menu level, press
Mode Selection
1. Go to MENU>SET.
2. Select GO WHITE.
3. Select YES?
DMX Addressing
1. Go to MENU >ADDRES.
2. Select the starting address [001~512].
3. Go to MENU >RUN.
4. Select DMX.
DMX Personality
1. Go to MENU>PERS and select any DMX personality.
2. Make sure to rearrange the DMX addresses of all products in the current DMX
universe to avoid address overlapping.
