Delta Electronics HMU1056H User Manual

Smt power inductor, Hmu1056h type, Mechanical dimension : features

background image

C

E

F

D

I

G

H

A

B

8.5

2.0

11.0

2.9

3.8

2.5

Mechanical Dimension :

Features

DELTA ELECTRONICS, INC.

(TAOYUAN PLANT CPBG)

252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com

At 25 : 100KHz, 1V

O

C

SMT Power Inductor

HMU1056H Type

Electrical Characteristics :

UNIT : mm/inch
A = 10.40 / 0.409 Max.
B = 10.40 / 0.409 Max.
C = 5.60 / 0.220 Max.
D = 1.40 / 0.055
E = 3.80 / 0.150
F = 2.90 / 0.114
G = 2.60 / 0.102
H = 5.50 / 0.217
I = 2.60 / 0.102

PART NO.

I

RATED

(Adc)

DCR

(m )

MAX

2

HMU1056H-R15

0.15

1.7

19.0

HMU1056H-0R3

0.30

2.4

17.7

HMU1056H-0R5

0.50

4.1

13.0

HMU1056H-0R8

0.80

5.3

11.2

HMU1056H-1R2

1.20

7.5

9.0

HMU1056H-1R5

1.50

10.5

7.8

HMU1056H-2R0

2.00

12.4

7.4

HMU1056H-2R5

2.50

18.0

6.2

HMU1056H-3R0

3.00

23.8

4.9

(uH)

1

L

131

1. Tolerance of inductance : 0.15~0.30uH 30% 0.50~3.00uH 20%
2. I

RATED

is the DC current which cause the inductance drop less than 35%

(20% typical) of its nominal inductance without current and the surface

O

temperature of the part increase less than 45

C.

O

O

3. Operating temperature : -20

C

to 105

C

( including self-temperature rise ).

RECOMMENDED PAD PATTERNS

RoHS compliant.
Low profile, SMD type.
High current.
Magnetic shielded.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Ideal for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here, customized inductors
are available to meet your exact requirements.
