LCP-1250RJ3SR-L EEPROM Serial ID Memory Contents (Two-Wire Address A0h)
Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII Address Hex ASCII
00 03 25 20 50 33 3 75 SN 100 00 125 00
01 04 26 20 51 53 S 76 SN 101 00 126 00
02 00 27 20 52 52 R 77 SN 102 00 127 00
03 00 28 20 53 2D - 78 SN 103 00
04 00 29 20 54 4C L 79 SN 104 00
05 00 30 20 55 20 80 SN 105 00
06 08 31 20 56 30 0 81 SN 106 00
07 00 32 20 57 30 0 82 SN 107 00
08 00 33 20 58 30 0 83 SN 108 00
09 00 34 20 59 30 0 84 DC Note 3 109 00
10 00 35 20 60 00 85 DC 110 00
11 01 36 00 61 00 86 DC 111 00
12 0D 37 00 62 00 87 DC 112 00
13 00 38 00 63 CS1 Note 1 88 DC 113 00
14 00 39 00 64 00 89 DC 114 00
15 00 40 4C L 65 01 90 DC 115 00
16 00 41 43 C 66 00 91 DC 116 00
17 00 42 50 P 67 00 92 00 117 00
18 64 43 2D - 68 SN Note 2 93 00 118 00
19 00 44 31 1 69 SN 94 00 119 00
20 44 D 45 32 2 70 SN 95 CS2 Note 4 120 00
21 45 E 46 35 5 71 SN 96 00 121 00
22 4C L 47 30 0 72 SN 97 00 122 00
23 54 T 48 52 R 73 SN 98 00 123 00
24 41 A 49 4A J 74 SN 99 00 124 00
Notes:
1) Byte 63(CS1): Check sum of bytes 0-62.
2) Byte 68-83 (SN): Serial number.
3) Byte 84-91 (DC): Date code.
4) Byte 95 (CS2): Check sum of bytes 64-94.
5) Byte 128-255 had been set hex.00.
LCP-1250RJ3SR-L Internal PHY Register (Two-Wire Address 0xAC)
LCP-1250RJ3SR-L is internally designed of physical layer IC (Marvell 88E1111), which can be programmed
via two-wire interface with the device address 0xAC. For details of PHY IC registers in 88E1111, see
Marvell document “
Alaska Ultra 88E1111 Integrated Gigabit Ethernet Transceiver”.
Electromagnetic Emission
FCC Class A, CE Class A, VCCI Class A, C-Tick
