Electrical Requirements Chart for D 1 Hot Tubs
Model
Power
Branch Circuit
Circuit Protection
Wire Gauge
Arena
240V, 30A
240V, 24A
3 wire + ground
3 wire + ground
40A
30A
#6 AWG
#8 AWG
Aurora II
240V, 38A
240V, 32A
240V, 24A
3 wire + ground
3 wire + ground
3 wire + ground
50A
40A
30A
#6 AWG
#6 AWG
#8 AWG
Aurora HP
240V, 38A
240V, 30A
240V, 24A
3 wire + ground
3 wire + ground
3 wire + ground
50A
40A
30A
#6 AWG
#6 AWG
#8 AWG
Aurora XLT
240V, 38A
240V, 32A
240V, 24A
3 wire + ground
3 wire + ground
3 wire + ground
50A
40A
30A
#6 AWG
#6 AWG
#8 AWG
Caliente
240V, 40A
240V, 30A
3 wire + ground
3 wire + ground
40A
30A
#6 AWG
#8 AWG
Caliente HP
240V, 50A
240V, 40A
240V, 30A
3 wire + ground
3 wire + ground
3 wire + ground
50A
40A
30A
#6 AWG
#6 AWG
#8 AWG
Californian
240V, 38A
240V, 32A
240V, 24A
3 wire + ground
3 wire + ground
3 wire + ground
50A
40A
30A
#6 AWG
#6 AWG
#8 AWG
Chairman
240V, 38A
240V, 32A
240V, 24A
3 wire + ground
3 wire + ground
3 wire + ground
50A
40A
30A
#6 AWG
#6 AWG
#8 AWG
Chairman II
240V, 38A
240V, 32A
240V, 24A
3 wire + ground
3 wire + ground
3 wire + ground
50A
40A
30A
#6 AWG
#6 AWG
#8 AWG
Diplomat
240V, 38A
240V, 32A
240V, 24A
3 wire + ground
3 wire + ground
3 wire + ground
50A
40A
30A
#6 AWG
#6 AWG
#8 AWG
Nautilus
240V, 38A
240V, 32A
240V, 24A
3 wire + ground
3 wire + ground
3 wire + ground
50A
40A
30A
#6 AWG
#6 AWG
#8 AWG
Triad
240V, 30A
240V, 24A
3 wire + ground
3 wire + ground
40A
30A
#6 AWG
#8 AWG
Triad II
240V, 30A
240V, 24A
3 wire + ground
3 wire + ground
40A
30A
#6 AWG
#8 AWG
