XAIRCRAFT Super X - Manual (Page 7)

4
©2013 XAircraft All Rights Reserved.
Products Electrical Features Weight Size
Flight Controller Input Voltage: 5.7V ~ 6.0V
Power consumption:

Max. : 3.5W（[email protected]）
 Normal: 0.6W（[email protected]）
65g Long: 42.1mm
Width: 34.2mm
High: 27.9mm
GPS Module 4.8V ~ 6.0V 58 g Diameter:74.4mm
High: 11.35mm
IO Module Input Voltage: 11.1V~28V（3S ~ 6S LiPo）
Output Voltage: 5.8V，≤3A
Power Consumption:

Max 3W([email protected]）
 Normal 0.13W([email protected])
35g Long: 56mm
Width: 37.5mm
High: 17.44mm
LED Module Power Consumption: 3W Long: 16.9mm
Width: 12.11mm
High: 7mm
SuperX Interface
