XAircraft MiniX OSD User Manual
Parameters
Input
Vol.
Video Input
Video
Output
Dimension
Weight
4.8~6V
1 Chn. Input
1Chn.Output
32.7mm x 18.8mm x 9.3mm
4.3
(not including cables)
Wiring
Port
Interface Type
Description
FC Port
4Pin Cable
Connect to FC
AVIN/AV OUT
4Pin OSD Cable
Connect to video transmitter and Camera
