XAIRCRAFT Super X - Manual (Page 18)

15
©2013 XAircraft All Rights Reserved.
6. Vertical Calibration B: Copter side up, and then revolve the copter slowly. When LED shows
solid green calibration done. If solid red calibration failed.
Copter side up Revolving slowly until LED solid on
7. Repower on to continue. If calibration failed, please recalibrate after power on.
RC Neutral Point Calibration
1. Cancel all trims on radio before calibration.
2. Fast altering Flight Mode switch between modes. When LED flashing red and green, the
controller enters Calibration Mode.
3. Center all sticks as the following picture, the LED shows double green flashing.
4. Keep sticks at neutral point, fast altering Flight Mode switch until led solid green, calibration
done.
5. Repower on.
RC Reverse Calibration
1. Fast altering Flight Mode switch between modes. When LED flashing red and green, the
controller enters Calibration Mode.
