WebDT DT362 User Manual

Page 3

DT362

ENGLISH

OPERATION

Internal Battery Switch

To prevent battery drain during shipping and extended storage, the internal battery may
be disconnected. To connect the internal battery, push the battery button switch (on the
back panel) to the “up” position (see page 2 for photo). The internal battery pack has to
be connected for it to operate, be charged, and for the optional external battery pack to
function.

Powering ON and OFF

To activate the DT362, push and quickly release the Power Button. The display will come
on in a few seconds. To put the DT362 in Standby mode, push and quickly release the
Power Button. To turn the DT362 oﬀ for extended storage, power oﬀ the device safely
using any software function that “shuts down computer” provided in the software
operating system.

NOTE: The battery packs shipped with your device may be low in power—please use
the AC-DC adapter with the DT362 when setting up the device for the ﬁrst time to
fully charge the internal battery pack. You may charge the external battery pack with it
attached to the DT362, or with the optional external battery charger kit.

NOTE: When the battery pack(s) is (are) charging, the blue-colored Battery LED should
blink slowly. If plugging in the AC-DC adapter does not trigger this blinking activity
and the LED stays dark, the battery pack(s) may have been drained substantially. Try
unplugging/ replugging the AC-DC adapter to the DT362 a few times to activate the
charging process.

NOTE: To conserve power, use (push and quick release) the Power Button to put the
device in “Standby” mode while not in use. Pushing brieﬂy on the same button will wake
up the system within seconds.

NOTE: Avoid using the Power Button (“hold 4+ seconds” feature) to turn oﬀ the
device—this form of hardware shutdown is intended to be a means of recovery from
device lockups, and not as normal operation.

Start Up

If the power up (from Standby or otherwise) is successful, the appropriate interface will be
displayed after a launch sequence of several seconds. The wireless LAN connection may take
10-15 seconds to be established.

Conﬁguring the DT362

The device may be conﬁgured using the utilities and methods dictated by the software
operating system. The DT362 should be conﬁgurable for various properties such as user
proﬁles, network features, and several system elements.

Calibration

The touch display for the DT362 is calibrated before shipping. In the event that the
calibration has been modiﬁed or is unsatisfactory, the respective calibration routines
(e.g., PenMount (PM) for Windows XP) to calibrate the touch interface may be used.
Such applications are typically executed through touch input via Stylus or through mouse
click via a USB mouse.

Wireless Networking

Wireless LAN

The DT362 is often delivered with an embedded (user-inaccessible) 802.11a/b/g/n
WLAN adapter equipped with a hidden custom antenna.

• hrough the support of typical WLAN adapters, the DT362 should be able to detect

all 802.11 access points in the vicinity for you to select the access point of your
choice for connection.

• he SSID and WEP/WPA/WPA2 (if enabled) parameters on the DT362 and the

access points have to match. The SSID is case-sensitive and it is recommended
that you enable WEP/WPA/WPA2 encryption (or advanced alternatives) for secure
access.

• hen WEP/WPA/WPA2 is enabled, you may need to consult your network admin-

istrator or your networking equipment literature to properly conﬁgure associated
settings such as Authentication mode, etc.

• efer to the access point operating manuals for setting up the 802.11 access points.
