Vortech Universal Big Block Carbureted System - Manual (Page 7)

P/N: 4GA020-030
©2008 Vortech Engineering, LLC
All Rights Reserved, Intl. Copr. Secured
08DEC08 V3.0(BBC LowMount(4GA..030 V3.0))
vii
008110 SMALL SILVER DIE CUT DECAL 2
008130 LICENSE PLATE FRAME, VORTECH 1
008443 S/C RACE INFO PKG ASSY VORT 1
4GA020-030 INSTR MAN, BBC LOW MOUNT KIT 1
4GA111-051 TENS. ASSY. COG, BBC DL PLT.LO 1
7G012-175 MACH NUT, COG DRV, SPECIAL 1
4FP017-021 SPACR, IDLR, DUAL PLT 50MM DRV 1
4FP116-020 IDLER W/BRNG ASSY, 50mm 1
4FD017-011 PILOT, 6203/5 BRG, 1/2 SCREW 1
7C012-065 M12 X 1.75 X 65MM HX 1
4GA111-061 BRKT ASSY, S/C MNT V4 BBC 1
4GA010-071 BRACKET,S/C BBC DUAL PLT RACE 1
4GA010-081 BRACKET,SPRT BBC DL. PLT RACE 1
2A017-049 SPACER A, SBCHEV CARB BRKT 8
4GA011-021 MACH MTG BRKT, BBC LOW MOUNT 1
7C012-022 M12 X 1.75 X 20MM THIN HD 3
7A375-126 3/8-16 X 1.25 HHCS, GR8, PLT 9
7A375-275 3/8-16 X 2-3/4 HXCSG8P ZINC 5
7A375-300 3/8-16 X 3" HXCSG5P 3
7K375-040 3/8 AN960 FLAT WASHR PLATED 19
7F375-017 3/8-16 NYLOCK NUT 2
7A437-200 7/16-14 X 2" SHCS 2
7A437-425 7/16"-14X4.25" HX HD 1
7J438-081 7/16 SAE WASHER PLATED 1
7A375-201 3/8-16 X 2" S.S. SHCS 2
7A375-426 3/8-16 X 4.25" HX HD GR8 1
4GA118-031 DRIVE ASY, BBC DUAL LOW COG 1
2A032-032 S/C PULLEY, 32T (50MM) 1
8R101-007 PULLEY RETAINER ASSY 50 MM COG 1
4MA018-080 CRANK PLY, 80T GT 8MM X 2.5W 1
4MA017-061 SPACER, CRK PLY, GEN2 V-GRV 1
4GA018-011 CRK PLY, ACC, BBC LNG H20 PMP 1
2A042-160 BELT, PC GT2 COG 1600X8MX36 1
7A375-475 3/8-16 X 4.75" HXHD GR8 PLTD 3
7K375-040 3/8 AN960 FLAT WASHR PLATED 3
4GA130-036 OIL DRAIN ASSY, BBC LOW MT 1
7U030-036 1/2" OIL DRAIN HOSE 2.5'
7R001-008 #8 STNLS HOSE CLAMP 2
7P375-017 3/8NPT X 1/2 BEADED HSE BRB 1
4MA130-026 OIL FEED ASSY BBC 1
4MA145-020 OIL FEED HOSE ASSY, BBCKIT 1
7P125-026 1/8 NPT X #4 SAE FLARE, 90° 2
7P125-034 1/8NPTX1/8NPT STRT T 1
7P125-103 1/8NPT X 45° -4SAE FLARE 2
7P250-036 -4 SAE FLARE TO 1/4 NPT 1
7P250-120 1/4 NPT PIPE PLUG 1
PART NO. DESCRIPTION QTY. PART NUMBER DESCRIPTION QTY.
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or damaged parts imme-
diately.
Base Kit, Universal BBC V4 Carb
Part No. 3GA218-060
PARTS LIST
®
ENGINEERING, LLC
